Functions and Features:
Wheelbase 140mm
Built-in OSD Betaflight
Support BLHeliSuit configuration
Support voltage 3-4S
Image transmission distance is about 500 meters
Remote control distance: FLYSKY remote control about 300 meters, T-pro remote control about 2000 meters
Battery life is about 5 minutes
Paddle
Type: 3016
Blades: 3
Material: PC
Weight/g: 1.18g
Diameter of support plate: 76.49mm
Center thickness: 5.5 mm
Maximum pillar width: 8.84mm
ESC and flight control integration
Integrated 35A 4in1 ESC F4 OSD flight controller
Size: 32.5×32.5mm
Mounting hole: 25.5 x25.5mm
Weight: 7.3g
CPU: STM32F411CEU6 (100MHz)
Microprocessor: MPU6000 (SPI)
Firmware: Betaflight JHEF411
BEC output (two): 9V / 2A, 5V2.5A
Receiver; Sbus, ibus, dsm2, dsmx, TBS (uart2)
Black box: 8mb
Built-in current sensor
Input voltage: 2-6S Lipo
ESC current: 35A
Firmware: BLHELI_S GH-30.hex
Support PWM, Oneshot42, Oneshot125, Multishot, Dshot150 and Dshot300, Dshot600
Motor
Mode: 1204
KV option: KV5000
Configuration: 9N12P
Stator Diameter: 12mm
Stator length: 4mm
Outer shaft diameter: 1.5mm
Motor size (Dia.*Len): 15mm*16.2mm
Weight (g): 5.9g
Number of batteries (Lipo): support 2-4s
Camera
Lens: 1.8mm
Aspect ratio: 4:3
Resolution: 1200TVL
Input voltage: DC3.7V-18V
Weight: 2g
Installation size: 14, 19mm
